Signal Amplifier XH108X1

  • DMX512 Signal Compatibility: Designed to amplify and distribute DMX512 digital lighting signals.

  • Eight Isolated Outputs: Features eight electrically isolated output channels for safe signal distribution.

  • High Voltage Isolation: Provides over AC300V electrical isolation between inputs and outputs to protect connected equipment.

  • Direct Signal Pass-through: Includes one direct-through output, electrically isolated from the main input.

  • Wide Power Compatibility: Operates on AC90V~240V with 50Hz/60Hz support and 15W consumption.

  • Compact Rack Design: Fits standard 19” racks in 1U space, with dimensions of 484 x 45 x 140 mm and weighing 1.9 kg.

Get Quotation
DETAILS
SPECS

The XH108X1 Digital Signal Distribution Amplifier is designed specifically for reshaping, amplifying, and distributing DMX512 digital lighting control signals with eight isolated outputs. Each input interface employs high-voltage isolation, making it suitable for amplifying DMX512 signals weakened by distance and providing complete electrical isolation between distribution output interfaces, and between input and output interfaces. This independent isolation prevents issues caused by control lines, moving lights, and dimmer packs, safeguarding the digital lighting control console from potential damage and ensuring the DMX signal reliably reaches lighting equipment, thereby enhancing the overall control system's reliability.

Specifications of Signal Amplifier


Model

XH108X1

Digital Signal Type

DMX512 Digital Signal Transmission

Signal Input & Output

1 Input, 1 Direct Output (Electrical Isolation Between the Signal Input and the Direct Signal)

Distribution Output

8 Electrically Isolated Outputs

Signal Connectors

Input - XLR-3-M; Output - XLR-3-F

Electrical Isolation (Input to Output)

AC300V

Power Supply

AC90V~240V, 50Hz/60Hz, 15W

Dimensions (mm)

484 × 45 × 140mm  19” 1U

Weight

1.9kg
