15.6 Inch Motorized Paperless System Dual-screen Interactive Monitor Lift D7615PZ / D7617PZ / D7618PZ

● With waterproof driver inside

● Support  1920*1080 resolution

● Support 7'' IPS Rear display

● Support 1 channel HDMI inputs and 1 channel VGA inputs

● Installed with DSPPA Paperless Conference System software

paperless conference system with lifting monitor & nameplate terminal


Datasheet
Get Quotation
DETAILS
SPECS
Diagram
15.6 Inch Motorized Paperless System Dual-screen Interactive Monitor Lift
15.6 Inch Motorized Paperless System Dual-screen Interactive Monitor Lift
15.6 Inch Motorized Paperless System Dual-screen Interactive Monitor Lift
15.6 Inch Motorized Paperless System Dual-screen Interactive Monitor Lift
15.6 Inch Motorized Paperless System Dual-screen Interactive Monitor Lift
15.6 Inch Motorized Paperless System Dual-screen Interactive Monitor Lift

Specifications of 15.6 Inch Motorized Paperless System Dual-screen Interactive Monitor Lift

Model

D7615PZ

D7617PZ

D7618PZ

Screen Size

15.6″

17.3

18.5

Horizontal viewing angle (degrees)

0~176°

Vertical Viewing Angle (degrees)

30~150°

Interface Resolution

16:9

LCD Resolution

1920*1080

Touch Technology / Surface Hardness

Condenser / Mohs Grade 7

Touch Points / Touch Response

10 points / <10g

Touch Reaction Time

5ms

Display Lift Angle

Mechanical automatic adjustment of 30 degrees

Rear Display Size (Touch not supported)

7 inch Resolution 1024*600

Input Interface

VGA*1, HDMI*1, Central Control*1, USB*2, , Switch*1

Output Interface

Central Control*1, Power Output Interface*1

Lifting Microphone

Asynchronously lift

Frequency Response

100~20K

THD

<0.5%

Input Sensitivity

35mV

Lifting Monitor Panel Interface

With USB interface *1 with USB dust cover

Shell Material

Aluminum Alloy

Color

Black/Silver

Power Supply

AC220V/50Hz

Power Consumption

100W

Working Temperature

-10℃~45℃

Working Humidity

10%~95%

Installation Method

Embedded electric lift installation

Package Size (L×D×H/MM)

488×132×660mm

545×132×660mm

575×132×745mm

Product Size

430×70×565mm

476×70×565mm

510×70×650mm

Panel Size

430×70×3mm

476×70×3mm

510×70×3mm

Panel Opening Size

431×71×3mm

477×71×3mm

511×71×3mm

Chassis Size

415×60×562mm

459×60×562mm

488×60×647mm

Chassis Opening Size

417×62mm

461×62mm

450×62mm

Gross Weight

10.6Kg

11.6Kg

12.9Kg

Net Weight

9Kg

9.9Kg

11.2Kg
