16-in 16-out Digital Audio Processor DT4300

  • Distributed system with Dante LAN digital audio transmission technique

  • No suppression, no dissipation and no delay, 48 kHz audio sampling

  • Dual network interface design

  • 16 channel balanced input and output

  • Independent control of line-in and line-out volume

  • 16 channel output with 7-level equalization adjustment in each. The 16th output is able to mix signals from channel 1 to 16

Datasheet
Get Quotation
DETAILS
SPECS
Diagram
16-in 16-out Digital Audio Processor
16-in 16-out Digital Audio Processor

Specifications of 16-in 16-out Digital Audio Processor

Model

DT4300

Item

Parameter

Measured when Balanced/ Unbalanced 1V/1kHZ input in this device and 1V unbalanced output form another DT4300 device.


Input sensitivity

≤1V

Input frequency response(±1dB)

20Hz~20kHz (±1dB)

Input noise

≥80dB

Input dynamic range

≥18dB

Input distortion

≤0.5%

Measured when unbalanced 1V/1kHZ input from another DT4300 device.

Output voltage

≥1V

Output frequency response(±1dB)

20Hz~20kHz (±1dB)

Output noise

≥80dB

Output distortion

≤0.5%





Independent adjustment of line output (PC control)


60Hz






±12±2dB

150Hz

400Hz

1kHz

2.5kHz

6.4kHz

15kHz

Protection

AC 220V/1A

Power supply

AC220V/50Hz

Machine size (L×W×H mm)

482×306×44

Package size (L×W×H mm)

526×348×86

Net weight

5.05KG

Gross weight

5.8KG
