Commercial Audio Desktop Conferencing and Paging Microphone with Dante Network Output DT4200P

  • It is well designed according to the principle of electroacoustics, with good frequency response characteristics and sound quality, clear and bright

  • Advanced surface processing technology, flexible hose processing method, feel good when bending

  • Applicable to all kinds of speeches, conferences, public broadcasting and sound amplification projects

  • Connectable to Ethernet directly without adding welding audio cable

  • Ethernet gigabit standard +48V POE power supply.

  • Simple mute function switch, easy to control when giving a speech

  • With a built-in windbreaker, which is able to reduce the noise when your speak


Datasheet
Get Quotation
DETAILS
SPECS
Diagram
Commercial Audio Desktop Conferencing and Paging Microphone with Dante Network Output

Specifications of Commercial Audio Desktop Conferencing and Paging Microphone with Dante Network Output

Model

DT4200P

Indicator

Parameter

Type

Desktop MIC

Output Frequency Response

50Hz-12kHz (±3dB)

Quiescent Dissipation

3W

Max Dissipation

≤5W

SNR

≥70dB

Crosstalk Attenuation

>75dB

Harmonic Distortion

<0.5%

Working Power Supply

Standard +48V POE power supply

Unit Interface

Network Interface

MIC

Type

Electret Cardioid Capacitive

Frequency Response

40Hz-20kHz (±3dB)

Sensibility

-27dBV/pa

Input Impedance

2kΩ

Equivalent Noise

125dB (THD<3%)

Max Sound Pressure Level

11dB (SPL)

Packing Size(mm)

(L×W×H) 485×265×135

Machine Size(mm)

(L×W×H) 146×116×42

Gross Weight

2.2 KG

Net Weight

0.6KG
