14-channel XLR balanced mono inputs and 2 stereo inputs.
12 independent PAD attenuation switches.
Independent noise gate switch for each input channel.
Independent 48V phantom power switch for each input channel.
3-band equalizer control for each input channel.
2 AUX SEND outputs.
Built-in DSP effects processor with 100 presets.
12 microphone input channels with independent 1*10-segment LED level meters for channel level monitoring.
Built-in USB audio playback function, supporting a variety of formats, including WAV, WMA, APE, FLAC, and MP3.
Dual-channel headphone monitoring.
2*10-segment LED level meters with pre-monitoring levels: [-20, -15, -10, -7, -4, -2, -0, +2, +4, +6 dB].
2 GROUP OUT outputs.
Dual-channel MAIN OUT stereo output.
High-reliability 60mm smooth-travel faders.
Designed for professional sound reinforcement, this series features flexible input and output configurations, channel-level control with noise gate and phantom power, studio-grade DSP effects, and reliable 60mm faders to ensure exceptional audio quality and operational stability. With 16-channel configurations, the series provides versatile solutions tailored to diverse professional environments.
Model | PM208 | PM212 | PM216 |
Maximum Output Level | 12dB | ||
S/N Ratio | ≥83dB (1MV IN 1V OUT) | ||
THD | ≤0.02% @ 0dB 1KHz | ||
Frequency Response | 20Hz~20KHz±0.5dB | ||
Channel Crosstalk | <-75dB @ 1KHz | ||
MIC IN Impedance | 600Ω | ||
LINE IN Impedance | 10KΩ | ||
Output Impedance | 100Ω | ||
MIC IN | -60dB | ||
LINE IN | -40dB | ||
Stereo IN Impedance | 10KΩ | ||
Channel Gain Control | -30dB | ||
3-Band Equalizer Adjustment Range | ±15dB | ||
HIGH | 12KHz | ||
MID | 4KHz | ||
LOW | 80Hz | ||
Power Supply Output Power | 30W | ||
Power Supply Voltage | 100V-240V/50Hz | ||
Package Dimensions (1 pc) | 424×176×526(mm) | 538×176×526(mm) | 648×176×526(mm) |
Product Dimensions | 370×450×125(mm) | 480×450×125(mm) | 590×450×125(mm) |
Gross Weight (1 pc) | 6.5KG | 7.2KG | 8.5KG |
Net Weight | 4.35KG | 5.6KG | 6.9KG |
