6 Mono input Channels with gold plated XLR and balanced Line Inputs
Ultra-low noise discrete Mic Preamps with +48 V Phantom Power
Balanced Inputs for highest signal integrity
Ultra-musical 2-band EQ on all channels
Peak LEDs all Mono Channels
1 Aux Send per channel for external effects and monitoring
Simulate effect (16 DSP)
Master Mix Output and rec output
Highly accurate 5 segment Bar graph Meters
Separate Master Mix Outputs
This audio mixer features 6 mono input channels with balanced XLR and line inputs, ultra-low noise discrete mic preamps with +48V phantom power, and musical 2-band EQ on every channel. With 16 built-in DSP effects, AUX sends, and precise LED metering, it delivers clear, professional sound and easy control for both live and recording applications.
Model | CM615 | |
Built-in Amplifier | Output Power | 120W × 2 / 8Ω |
Mono Inputs | Mic Input B | Electronically Balanced, Discrete Input Configuration |
Bandwidth | 20Hz to 20kHz ±3dB | |
Distortion (THD & N) | 0.01% at +4dBu, 1kHz, Bandwidth 80kHz | |
Mic E. I. N (20Hz-20kHz) | -96dBu, 150Ω Source -102dBu, 150Ω Source -110dBu, Input Shorted -108dBqp, Input Shorted | |
TRIM Range | +10dB to 20dB | |
Line Input | Electronically Balanced | |
Bandwidth | 10Hz to 60kHz ±3dB | |
Distortion (THD & N) | 0.01% at +4dBu, 1KHz, Bandwidth 20kHz | |
Line Level Range | +10dBu to 4dBu | |
Equalization | Hi Shelving | 12kHz +/-15dB |
Mid Range | 2.5KHz +/-15dB | |
Lo Shelving | 80Hz +/-15dB | |
Master Mix Section | Max Output | +22dBu Balanced |
Aux Send Max Out | +22dBu Unbalanced | |
Control Room Out | +22dBu Unbalanced | |
SNR | +112dBu, All Channels at Unity Gain | |
Power Supply | Mains Voltages | AC220V-240V, 50-60Hz |
