Built-in 100v/70v transformer
In-ceiling type loudspeaker
5” paper cone driver unit
Rated power output at 20W
High sensitivity(90±2dB)
With voltage and ohms terminal
ABS white engineering plastic
Secure flush mount installation
The DSP915D is a ceiling speaker of Public Address System.The speaker driver is designed of wide frequency response (60Hz-20kHz), and rated power output is 20W; It is made of high quality engineering plastic, which ensures long-term durability, and will never be out of shape; Construction of dual-crossover, its flush mount type makes the easy and secure installation possible; Driver surround excellent damping, long life, clear and sonorous sounds.It is an ideal choice for industrial and commercial applications in hotel, school, office and factory where background music and paging is needed.
Model | DSP915 |
Full-range | 5” x 1, 1” x1” |
Rated Power | 20W |
Line Input | 70/100V, 4-16Ω |
Sensitivity (1M,1W) | 90dB±2dB |
Max SPL(1M) | 103dB±2dB |
Freq. Response | 60Hz-20kHz |
Cutout Size | Ø170 mm |
Dimensions (H x W x L) | 224 x Ø198mm |
Weight | 2.9kg |
