55 Inch 4K Dual-System Interactive Flat Panel

55 Inch 4K Dual-System Interactive Flat Panel DCP-8755

Whole machine structure: full aluminum profile + fully tempered glass + zinc alloy corner code + mold sheet metal + internal structural parts + plug-in module + wall bracket (optional mobile or pedestrian bracket);
Display configuration: 4K soft screen, 4KUI, tempered high-transparency glass optical anti-glare;
Supported pixels: 4K (3840*2160);
Backlight scheme: D-LED type, color gamut: 85%NTSC (typical value);
Android configuration: V100:8G running, 128G memory;
Computer configuration: optional (OPS computer module), which can be combined with corresponding schemes according to requirements;
Infrared touch: 40-point high precision touch scheme, supporting single point/multi-point touch and writing;
Sound scheme: front surround dual speakers, active noise reduction: full bass, bright high sound;
System switch: touch the screen, one-click switch, powerful function, simple operation;
Product functions: automatic light sensing, remote conference, wireless screen projection, whiteboard writing, multi-channel writing, child lock, screenshot sharing, arbitrary annotation, mobile phone scanning code, etc.

Datasheet

Get Quotation

DETAILS

SPECS

This series interactive flat panel combines advanced display technology with an elegant and durable design. Featuring a 4K soft screen with high-transparency tempered glass and an anti-glare surface, it delivers vivid and comfortable visuals for classrooms, meeting rooms, and collaborative spaces. With its full aluminum profile structure, high-precision infrared touch technology, powerful Android system, and optional OPS computer module, the panel ensures efficient operation and smooth interaction. It also supports diversified hardware expansion, including optional screen projectors, providing flexible solutions for different application needs.

Model	DCP-8755	DCP-8765	DCP-8775	DCP-8786
Machine Parameters
Body Material	Profile: anodized, upper and lower space gray + left and right frosted black Code: gun gray zinc alloy electroplating Back cover: black powder coated sheet metal; stable structure, active heat dissipation
Front Frame Glass	Physical fully tempered 7 grade explosion-proof glass, optional AG anti-glare treatment
Overall Machine Size	(L) 1265.6 * (W) 763 * (T) 85mm (including wall bracket thickness 107.9mm)	(L)1485.8 * (W) 888 * (T) 84.8mm (including wall bracket thickness 111mm)	(L) 1708 * (W) 1013.2 * (T) 85mm (including wall bracket thickness 113mm)	(L) 1954 * (W) 1152.9 * (T) 86.1mm (including wall bracket thickness 120mm)
Pacakge Size	(L)1370(W) 920(T)200mm	(L)1600(W) 1000(T)200mm	(L)1850(W) 1155(T)225mm	(L)2110(W) 1285(T)225mm
Product Weight	23KG (Net weight) 30KG (Gross weight)	32KG (Net weight) 42KG (Gross weight)	45KG (Net weight) 58KG (Gross weight)	56KG (Net weight) 73KG (Gross weight)
Overall Power	≤ 140W (excluding OPS) Supports OPS power: 95W	≤ 160W (excluding OPS) Supports OPS power: 95W	≤ 180W (excluding OPS) Supports OPS power: ≤ 95W	≤ 370W (excluding OPS) Supports OPS power: ≤90W
Standby Power	≤0.5W	≤0.5W	≤0.5W	≤0.5W
Speaker	2*10W stereo full-range speakers	210W stereo full-range speakers (Optional 215W)	210W stereo full-range speakers (Optional 215W)	210W stereo full-range speakers (optional 215W)
Input Voltage	AC90~264V (50/60Hz)
Display Parameters
Panel Size	55 inches (16:9)	65 inches (16:9)	75 inches (16:9)	86 inches (16:9)
Backlight Type	D-LED	D-LED	D-LED	D-LED
Display Area	1211.6 (H) × 682.4 (V)	1430.5 (H) × 805.5 (V)	1652.2 (H) × 930.3 (V)	1897 (H) × 1068 (V)
Resolution Ratio	3840 (H) × 2160 (V) (UHD)	3840 (H) × 2160 (V) (UHD)	3840 (H) × 2160 (V) (UHD)	3840 (H) × 2160 (V) (UHD)
Coloration	10bit, 1.07B	10bit, 1.07B	10bit, 1.07B	10bit, 1.07B
Luminance	Central Point ≥350 cd/㎡	Central Point ≥350 cd/㎡	Central Point ≥350 cd/㎡	Central Point ≥350 cd/㎡
Contrast Ratio	≥4000：1（Typ.）	≥4000：1（Typ.）	≥4000：1（Typ.）	≥4000：1（Typ.）
View Angle	178°（H）/178°(V)	178°(H) / 178°(V)	178°(H) / 178°(V)	178°(H) / 178°(V)
Backlight Life	> 50,000 hours	＞50,000 hours	＞50,000 hours	＞50,000 hours
Touch Parameters
Touch Standards	Promethean standards for UNESCO suppliers
Touch Embedding Mode	Built-in all-in-one
Writing Style	Finger, stylus or other opaque object> 1.5mm
Number of Touch Points	Forty points
Touch Resolution	32768*32768
Touch Accuracy	±1mm
Refers Only to Response Speed	≥6ms
Number of Touches	Theoretically, the number of times is infinite
Drivers	Automatic system recognition, no driver
Support System	windows7/10/11, Android, Mac OS	windows7/10, Android, Mac OS	windows7/10, Android, Mac OS	windows7/10, Android, Mac OS
Working Temperature	-10~+50 ℃	-10～+50°C	-10～+50°C	-10～+50°C
System Parameters
CPU	Cortex- A55*8 The main frequency is 1.2GHz
GPU	Mali-G52 MP2
Run Memory	8G
Internal Storage	128G
System Version	Android 14.0
Optional Computer Configuration
Chip Configuration	Intel Core I3/I5/I7
OPS Algebra	Generation 3/4/6/8/9/10/12/13
Run Memory	4G DDR3/DDR4 4G / 8G / 16G
Solid State Disk	128G / 256G / 512G/1T/2T
Video Card	Intel Core graphics card Intel HD Graphics
Operating System	Windows 7 flagship operating system (standard) Windows 10 operating system (optional)
Android Port Parameters
Rear Port	RJ451, (Mini)LINE OUT1, OPTICAL OUT1, RS2321, USB (USB2.02 HDMI IN2, TOUCH OUT(USB 2.0)1, MIC IN1, LINE OUT1, TF IN1, HDMI OUT*1
Front-end Port	HDMI IN1, USB2, Touch USB1, Type-C1
List of Accessories
Standard Layout	Magnetic pen 1, remote control 1, power cord (1.5m) 1, wall bracket 1, instruction manual *1
Optical Configuration	Wireless screen projector, smart page turning pen, HDMI cable (1.5m)
Installation Parameters
Working Temperature	-10+50℃
Working Humidity	10%RH~90%RH
Storage Temperature	-20℃~60℃
Store Moisture	10%RH~90%RH
Way to Install	Wall mounting (optional pedestrian bracket or mobile trolley)
Wall Bracket Hole Distance	(L)400*(W)400mm
Power Type/Mode/Interface	Three-core power supply/fixed/pinhead
Inbuilt Installation Principle	Signle side +20mm
