Professional Conference System Solution for Court

2023 Guangzhou DSPPA Audio Co., Ltd.
Sound Reinforcement System for Court

Sound Reinforcement system is designed to solve the problem of poor transmission of speech in the court and difficulty for the audience to hear clearly. During the court trial, judges, lawyers, witnesses and others need to speak, and the trial site is usually crowded with people, the space is complex, there are problems such as noise interference and scattered audience positions, which brings difficulties to the transmission and hearing of speech sounds.


Request a demo
Professional Conference System Solution for Court
Professional Conference System Solution for Court

Installation Effect


The design of the sound reinforcement system for the court needs to take into account audio input, audio processing, sound reinforcement equipment, control systems, system integration, and security and confidentiality for clear sound reinforcement and effective transmission of court speech.

图片1.png Pure Speech Reinforcement Configuration


● The 250㎡ trial division is equipped with four 250W 10-inch two-way full-range speakers.

● System Composition: Speech System + Professional Sound Reinforcement System.

● The system functions as pure speech and audio reinforcement.










No.

Model

Product Name

Quantity

Audio System

1

D6561

Stand Wired Microphone

2

2

D6560

Desktop Condenser Microphone

9

3

D5821

UHF Wireless

Microphone System

1

4

DX12

12-Channel Audio Mixer

1

5

D6573

Feedback Suppressor

1

6

D6642H

Digital Audio Processor

1

7

MX2500II

Professional Stereo Amplifier

2

8

D6564

10" Two-way Full

Range Speaker

4

Peripheral

1

D6572II

Sequence Controller

1

2

D5A

Wall Mount Kits

4

3

D7A

Microphone Stand

2

4

MP40U

40U 19" Floor Stand Audio Rack with Electric Fan

1







图片1.png Multi-system Integration Extension



● Matrix System: The signal distribution system needs to be responsible for managing computer signals and indoor camera signals from the lawyer's bench, podium, judge's bench, and witness box, and switching to the corresponding display screen.

● Video Conference System: In court applications, it can be used as a remote trial or as a sub-venue auditor.

● Recording and Broadcasting System: records the entire court judgment process for live playback.




图片2.png Installation Effect












图片1.png Pure Speech System + Recording&Broadcasting System + Video Conference System + Matrix System Configuration


System Composition: Pure Speech System + Recording and Broadcasting System + Video Conference System + Professional Sound Reinforcement System + Matrix System.

System Functions: pure speech, recording or live broadcasting, remote video conferencing, signal switching, audio sound reinforcement.










No.

Model

Product Name

Quantity

Audio System

1

D6561

Stand Wired Microphone

2

2

D6560

Desktop Condenser Microphone

9

3

D5821

UHF Wireless

Microphone System

1

4

DX12

12-Channel Audio Mixer

1

5

D6573

Feedback Suppressor

1

6

D6642H

Digital Audio Processor

1

7

MX2500II

Professional Stereo Amplifier

2

8

D6564

10" Two-way Full

Range Speaker

4

Recording&Broadcasting System+Video Conference System+Matrix System

1

D6284

HD Conference Camera

3

2

DSP9203

HD Conference Record System Host

1

3

HD 8102

HD Video Conferencing terminal

1

4

HD 8000

HD Video Conference MCU (16 channels)

1

5

D6108

HD Seamless Mixer Matrix

1

Peripheral  Equipment

1

D6572II

Sequence Controller

1

2

D5A

Wall Mount Kits

4

3

D7A

Microphone Stand

2

4

MP40U

40U 19" Floor Stand Audio Rack with Electric Fan

1







图片1.png Product Introduction


Professional Speaker D6564

● Phased-inverted low-frequency radiated two-way loudspeaker system;

● Wooden case processing by water-based paint spraying with the black spot on the surface perforated metal mesh acoustic penetration cotton;

● Built-in efficient and high-quality unit; Suitable for suspension instalment.

● Driver Unit: 10" Bass×1, 1" Treble×1; Rated Power: 250W

● Dimension (H×W×D): 515×315×287mm; Weight: 14.6kg










● The sound effect of the two-way full-range speaker is more balanced, which can better restore the details and expressiveness of the music, and can give people a more comfortable feeling.

● It is also suitable for professional performance venues, various conference venues, mobile performances, squares, shopping centres and other places.






Video Conference System

● Convene conferences with video remote conference system to quickly and efficiently communicate policy, decision-making, or superior meeting spirit to all departments, reducing business travel time and costs for staff and greatly improving office efficiency.

● Multi-level Conferences: International, cross-regional, and cross-city meetings can be held independently, or multi-level groups can hold conferences in a unified manner, and support meetings under multiple networks and different bandwidth environments.

● Remote Video Control: The management and control center can remotely control the cameras in each conference room, and uniformly schedule the video images.

● Remote Control: The control centre can remotely control the video in each conference room, including viewing screen selection, screen definition adjustment, conference speech settings, etc.













Recording & Broadcasting System Advantages

● The system includes a module for automatic implementation of RTMP stream and supports live broadcasting on both LAN and WAN networks.

● Support iPhone/iPad/Android and other mobile terminals to enjoy borderless webcasting.

● Browsers can directly enter the host IP to watch the live broadcast, without the need to install any software.



What’s the Recording & Broadcasting System?

The recording and broadcasting system is to collect the video, audio and image signals of electronic equipment (including computers and physical exhibition stands) in real-time for integration and synchronous recording, generating standardized streaming media files for external live broadcast, interaction, storage and on-demand, etc.








The embedded 2.0-inch display screen of the recording and broadcasting host can display: the equipment model, classroom or conference room name, local IP, working status, equipment temperature, date and time, etc., and can quickly set and query the host status.





Matrix System

● Intelligent matrix system for audio and video signal switching. The signal cards compatible with different audio signal input/output cards include HDMl, DVI, VGA, SDI, and AV seamless input/output signal cards.

● It supports multiple signal input and output intermixing matrix switching and provides the independent video signal and audio input and output terminal.

● The audio and video signals of each video signal are transmitted and switched separately to minimize the attenuation of signal transmission. Image and sound signals can be output with high fidelity and can be randomly matched with input and output signal cards.

● Support power-off protection, power-off memory, audio and video synchronization or separate switching.
