The woofer employs a 35mm voice coil ferrite driver.
The driver utilizes ferrite magnets with high stability, heat resistance, and slow thermal demagnetization effects.
The cabinet adopts precise CNC machining combined with grooved wedge-joint technology for robust durability.
Application scenarios: Homes, conference rooms, multi-function halls, quiet bars, shopping malls, and public spaces.
The product driver employs ferrite magnets with high stability, excellent high-temperature resistance, and slow thermal demagnetization effects. The enclosure adopts precise CNC machining combined with groove-wedge jointing technology for robust durability. It is suitable for various applications: conference rooms, multifunctional halls, bars, shopping malls, and public areas.
Model | DSP26SII | |
Frequency Response | 50Hz-250Hz (±3dB) | |
Sensitivity | 96dB | |
Max. SPL. | 114dB (Continuous) / 120dB (Peak) | |
Power (AES): Rated / Program / Peak | 100W (RMS) / 200W (PROGRAM) / 400W (PEAK) | |
Power Adjustment | 4Ω | 100W |
100V | 200W-100W-50W | |
Bass Unit | 1×8” | |
Input Interface | 7P Terminal Block | |
Dimensions | 400 × 520 × 150mm | |
Net Weight | 10 kg | |
