Modular design enables flexible speaker combinations.
Delivers optimal sound coverage and uniform distribution.
System sensitivity: 98dB sensitivity; 130dB Max. SPL.
Built-in high-efficiency independent power amplifier, with total output power up to 2400W.
Ensures clear and intelligible audio even in noisy environments.
Coated with advanced polyurea waterproof paint, reaching an IP66 waterproof level.
Features strong resistance to dust, water, and moisture.
Maintains stable and reliable performance in harsh conditions.
The Professional Waterproof Active Line Array Speaker System is engineered for demanding applications that require exceptional sound quality, robust amplification, and reliable weather resistance. It can reach IP66 waterproof protection level, further enhanced by a durable polyurea coating, making it built to handle outdoor stages, open-air events, humid auditoriums, and large conference rooms where moisture is a concern. Beyond its weatherproof construction, the system delivers powerful, high-fidelity audio with exceptional projection, capable of filling even the largest venues with clear and impactful sound regardless of the environment. Whether deployed for an outdoor performance, a school assembly, or a critical conference, this system seamlessly unifies professional-grade acoustic performance with rugged waterproof protection.
Model | DSP1280F |
Frequency Response | 35Hz-20KHz(±3dB) 1watt@1m |
Sensitivity | Full-Range Speaker: 96dB Subwoofer: 95dB Whole System: 98dB |
Max.SPL | Full-Range Speaker: 125dB Subwoofer: 124dB Whole System: 130dB |
Nominal Impedance | 4 Ohm |
Nominal Power | 800W Full-range Speaker, 800W Subwoofer |
Peak Power | 3200W |
Dispersion H x V | 140° Horizontal * 25° Vertical |
Crossover Point | Active 150Hz, Built-in Mid and High-frequency Drivers: 1.2KHz |
HF drivers | 2 ×1.75” HF drivers (44-turn voice coil tweeter) |
MF drivers | 6 × 5.5" Midrange drivers (35mm voice coil) |
SUB drivers | 2 × 12" Subwoofers (75mm voice coil) |
Active Power Amplifier | 2×1200W |
Paint | Polyurea Waterproof and Scratch-resistant Paint |
Product Dimensions | Upper Column Speaker: 700H × 150W × 190D (mm) |
Lower Column Speaker: 650H × 150W × 170D (mm) | |
Subwoofer: 860H × 340W × 350D (mm) | |
Net Weight | Upper Column Speaker: 14kg |
Lower Column Speaker: 11kg | |
Subwoofer: 32kg |
