● 2×150W/8Ω, the full range of digital amplifiers supports 4Ω load.
● Work with a rotary encoder (shuttle) for the main operation. Each sound source has an independent volume button to facilitate volume operation, with a simple interface to prevent misoperation.
● With a built-in player, it supports the visual display of songs and supports the previous song, next song, pause, loop play, etc.
● With 2 microphone balanced inputs on the rear panel, 2 6.35mm microphone inputs, with separate volume adjustment, with reverb effect processing and 7-band digital equalization adjustment for the microphone input, and microphone anti-whistling function.
● With 3 audio lines, independent volume adjustment, 7-band digital equalization adjustment and multiple preset effects.
● With 1 audio line (stereo) output.
Model | DK6915 | DK6925 | DK6935 | DK6950 | DK6965 | |
Microphone Input Sensitivity | 5mV-250mV adjustable | |||||
Line Input Sensitivity | 250±25mV | |||||
MP3 Input | -10dB/1KHZ | |||||
Line Output Voltage | 1000±100mV | |||||
Total Harmonic Distortion | ≤0.5 (1KHz, under normal operating conditions) | |||||
Line Frequency Response | 20-20kHz (±3dB) | |||||
Microphone Frequency Response | 80-20kHz (±3dB) | |||||
10-Band Equalization for Microphone | 31HZ: ±12dB 63HZ:±12dB 125HZ: ±12dB 250HZ: ±12dB 500HZ: ±12dB 1KHZ: ±12dB 2KHZ: ±12dB 4KHZ: ±12dB 8KHZ: ±12dB 16KHZ: ±12dB | |||||
10-Band Equalization for AUX | 31HZ: ±12dB 63HZ:±12dB 125HZ: ±12dB 250HZ: ±12dB 500HZ: ±12dB 1KHZ: ±12dB 2KHZ: ±12dB 4KHZ: ±12dB 8KHZ: ±12dB 16KHZ: ±12dB | |||||
10-Band Equalization for MP3&BT/LINE | 31HZ: ±12dB 63HZ:±12dB 125HZ: ±12dB 250HZ: ±12dB 500HZ: ±12dB 1KHZ: ±12dB 2KHZ: ±12dB 4KHZ: ±12dB 8KHZ: ±12dB 16KHZ: ±12dB | |||||
S/N Ratio (A-weighted) | ≥85dB | |||||
Operating Power | AC220V/50-60Hz | |||||
Phantom Voltage | +48±5V | |||||
Rated Power | 2×150W/8Ω/2×250W/4Ω | 2×250W/8Ω/2×350W/4Ω | 2×350W/8Ω/2×550W/4Ω | 2×500W/8Ω/2×750W/4Ω | 2×650W/8Ω/2×950W/4Ω | |
Gross Weight | 7.15kg | 7.65kg | 8.45kg | 9.5kg | 9.6kg | |
Net Weight | 5.45kg | 5.95kg | 6.75kg | 7.8kg | 7.9kg | |
Outer Package Dimensions (L×W×H mm) | 530*518*155MM | 530*548*155MM | ||||
Machine Dimensions (L×W×H mm) | 430*360*88MM | 430*390*88MM | ||||
