32 Channels Digital Mixing Console CM32

  • 10.1″ capacitive touch screen 1280×800 resolution.

  • 17 100mm electric faders.

  • Can switch between Chinese and English interfaces at any time without reboot.

  • With built-in USB recording and playback functions.

  • Support playback of APE, FLAC, MP3, WAV lossless audio formats.

  • Can recognize Chinese song names with the USB player.

  • With built-in 16-channel independent feedback suppressors.

  • With 8 DCAs.

  • Support iPad touch screen full-featured control, and real-time data synchronization.

  • Support 8 terminals to control simultaneously.

  • With built-in 2 effect modules.

  • Can upgrade the ARM firmware and DSP firmware through the network or USB resistance disk.

  • With 4-band parametric EQ, noise gate, feedback suppressor, high and low pass, compressor, and inverter for each input channel.

  • With parametric EQ, high and low pass, compressor, inverter, and 1s delayer for each output channel.

  • With output channels: L/R, 10 BUS, HeadPhone(L/R).

  • Can select pre-fader or post-fader (PRE/POST) for 10BUS mix bus.

  • Support 100 groups of scene preset function, and can export and import USB storage, convenient for data backup.

  • Support 32 PEQ modes storage.

  • With built-in signal generator: sine wave, pink noise, white noise.

  • With channel parameter copy function, the same channel can quickly copy data.

  • Support wiring method: balanced input and output XLR.

  • With 8 fader groups, 8 user-defined buttons, and 4 quick mute buttons.

  • With panel lock button (to prevent misuse).

  • Support customized channel name.


Datasheet
Get Quotation
DETAILS
SPECS

Specifications of 32 Channels Digital Mixing Console

Model

CM32

Analog Input

32CH (MIC/Line)

Analog Output

L/R+10BUS+REC+Headphone(L/R)

Noise Floor

-90dBu unweighted, AES17 (20Khz)

THD+N

Distortion

0.005% @4dBu 1Khz

0.01% @4dBu 20~20Khz

SNR

108dB unweighted

Dynamic Range

108dB unweighted

Maximum Input Level

Balanced 20dBu

Maximum Output Level

Balanced 20dBu

Frequency Response

20Hz-20KHz ±0.5dB

Screen Size

10.1″

Resolution

1280×800

Touch Control

Capacitive

Main Control CPU

Samsung 4418 quad-core Cortex™-A9

Boot Speed

36 seconds

Operating System

Linux

DSP

ADSP-21489 400Mhz

USB

Recording and playback (APE, FLAC, MP3, WAV playback formats)

DCA

Support

Chinese and English Interface

Support

Electric Faders

17

iPad Control

Support

Effect

2 effect buses (6 preset effect parameters, 24 users storage)

Feedback Suppressor

16, independent

Ethernet

Support

RS-232 Protocol

Support

USB Mouse

Support wired USB mouse

Power Supply

AC 100V-240V; 47~63Hz  100W

Dimensions (W*D*H)

610×650×230mm

Net Weight

22.1kg

Package Weight & Dimensions

39.5kg (Flight case packaging) 800×710×350mm

26.5kg (Carton packaging) 758×735×350mm

USB Mouse

Support

Dimensions (W*D*H)

535×485×205mm

Power Supply

AC 100V-240V; 50/60Hz  55W

Net Weight

10.7kg

Gross Weight

14.9kg

Package Dimensions

635*580*335
