Conference Mixer Amplifier with 6 Mic Input and EQ Control (120W) MP6912

  • Convenient and reliable working mode, integrated functional design.

  • 4 LINE IN, 1 LINE OUT, 6 MIC IN (Balanced, ungrounded, with 24 V phantom power supply).

  • Can automatically detect the input status of 4 audio source channels after powered on, and output the signal with the higher priority first.

  • professional digital mixing amplifier with the mute function, easy to override normal playing.

  • The priority of the 4 audio source channels: AUX1, AUX2, AUX3, AUX4.

  • Adopt DSP frequency shift processing for the microphone, with frequency shift function.

  • With built-in chime generator, adjustable chime output volume.

  • With independent volume control for microphones and audio source channels, and master volume control for amplifier output.

  • 7-band EQ, easy for adjustment, with EQ/Bypass option for output.

  • With 100 V and 70 V rated voltage output, P1 output.

Datasheet
Get Quotation
DETAILS
SPECS
Conference Mixer Amplifier with 6 Mic Input and EQ Control (120W)
Conference Mixer Amplifier with 6 Mic Input and EQ Control (120W)
Conference Mixer Amplifier with 6 Mic Input and EQ Control (120W)
Conference Mixer Amplifier with 6 Mic Input and EQ Control (120W)

Specifications of Conference Mixer Amplifier with 6 Mic Input and EQ Control (120W)


Model

MP6906

MP6912

MP6935

Rated Output Power

60W

120W

350W

Output Voltage Regulation

From full load to no load, ≤3dB

MIN. EMF.

MIC: ≤3mV (Unbalanced input)

MIC: ≤3mV (Balanced input)

LINE: ≤300mV

Frequency Response

80Hz -16KHz (±3dB)

THD

≤0.5 (1KHz, under normal working condition)

SNR

LINE: ≥70dB

7-band EQ

64HZ: ±12dB

160HZ: ±12dB

400HZ: ±12dB

1KHZ: ±12dB

2.5KHZ: ±12dB

6.4KHZ: ±12dB

15KHz: ±12dB

Protection Function

DC, overload, short circuit.

Mute Function

MIC1 and chime input override other inputs.

Phantom Power

DC24V

Frequency Shift

0-5Hz higher than the input signal frequency

Working Power

AC220V/50Hz

Rated Power Consumption

120W

250W

650W

Package Dimensions (mm)

(L×W×H) 555×455×185

Machine Dimensions (mm)

(L×W×H) 430×368×88

Gross Weight

12kg

13.8kg

17.8kg

Net Weight

10.2kg

12kg

16kg
